Excavating the Soil
Choose a building area on stable ground away from obstructions. When a nuclear weapon detonates, it creates a thermal pulse which can set things 20 mi (32 km) away on fire. You can often build a shelter in your backyard if you can position it so that both rainwater and water behind dams runs away from it. You will also need to consider where the utility lines are in your area so you don’t disturb them. Try to select stable ground where trees and buildings won’t fall on your shelter. If you’re in a city, you can build a reinforced shelter in a basement. The concrete can protect you from fallout and falling debris. Research the topography of your area. Your government’s local land survey office will have them available. Also, check with the emergency response office. Avoid positioning your shelter downhill from bodies of water or below steep slopes. Keep it clear of flammable buildings.
Print out a blueprint for the shelter you want to make. Having a clear blueprint will help you construct a stable, effective shelter. You can find some basic plans simply by searching for fallout shelter blueprints online. Some plans may even include a step by step overview for building the shelter. You can also get blueprints by consulting an architect or drafter. They can provide guidance on what shelter best suits your needs. Most building construction companies can build a shelter for you. Even if you don’t want to hire someone to design a shelter, sketch your own plans before beginning construction. You can try using a computer program like SketchUp.
Stake out and clear the building area for construction. Plot out the shelter’s perimeter according to your blueprint. Plant a series of wooden stakes in the ground to outline the shelter’s perimeter. Then, use shovels, axes, and other tools to dig up grass, trees, rocks, and other debris in the area. Clear the land about 10 ft (3.0 m) beyond the shelter’s perimeter so you have plenty of space to work with. The shelter’s size is up to you. Expect to add about 3 ft (0.91 m) to the shelter’s length for every person who will hide there. A basic 4-person shelter is about 10 × 10 × 10 ft (3.0 × 3.0 × 3.0 m) in size.
Dig a trench and move the dirt out of the excavation area. Begin digging out soil to form the basic outline of your shelter. You can do this with shovels, although it takes a lot of time and labor. Move the excavated dirt 10 ft (3.0 m) beyond the stakes. You will need to keep the dirt away so it doesn’t fall back into the trench. For quicker work, rent a backhoe from an equipment company near you. This can get pricey, but speeding up the excavation process is often worth it. Digging a deeper trench means more space and blast protection for your shelter.
Create an emergency exit at the far end of the trench. The emergency exit will also serve as extra ventilation. At the end of the trench, dig a crawl space about 2 ft (0.61 m) wide and 3 ⁄2 ft (1.1 m) deep. The crawl space will be right below the soil’s surface. Create an exit at the end by digging a small trench to connect the crawl space to the outside world. You can build dirt steps as needed to reach the surface. Pile dirt near the entryway, then begin digging into it with a shovel. Shape the dirt into small steps. Lay threshold boards over each steps, connecting them to side boards with 10 in (25 cm) lag bolts. Always have a second exit in your shelter to guard against emergencies.
Make a second crawl-way for the entrance. Create the main entryway the same way you built the emergency exit. This time, dig on the opposite end of the shelter. You can make this entryway a little wider so you have an easier time entering the shelter. Keep the entryway below ground, emerging away from the shelter’s main living quarters. The main entrance will not have air pumps or ventilation pipes running through it, so it may appear larger by default.
Creating the Shelter Roof
Lay wooden roofing poles side by side over the trench. Get poles that overhang the trench by at least 2 ft (0.61 m) so they are less likely to collapse. Lay them across the trench’s width. Push the logs as close together as possible to reduce the gaps in the shelter’s roof. For example, try using 9 ft (2.7 m) poles over a trench 5 ft (1.5 m) wide. Roofing poles are basically long, uncut pieces of timber. You can get them from lumber yards. Roofing suppliers and home improvement stores may also be able to help.
Stack poles in front of the entryways to keep dirt out of them. Lay a few 6 ft (1.8 m) wooden roofing poles between the trench and the edge of each entryway. Use about 3 or 4 logs on each side. Tie them together with strong rope or wire, also binding them to the closest poles hanging over the trench. These entryway poles hold back the dirt you will use to create the shelter ceiling. If you don’t have them in place, the dirt can slide into the entryways, blocking them.
Waterproof the logs with a tarp or another plastic material. Make sure you cover any gaps between the logs so water and dirt can’t fall into the shelter. You can do this easily by purchasing a tarp large enough to fit over the trench. Also try overlapping a few smaller tarps. You can also fill the gaps with cloth, leaves, clay, or other alternative materials.
Cover the logs with an 18 in (46 cm) earth dome. Begin moving the excavated dirt back on top of the logs. Make sure the dirt is unable to leak into the living space below the logs. As you pile up the dirt, shape it into a rounded mound ending right before the shelter’s entrances. The mound shape will give your shelter’s roof plenty of stability to prevent it from caving in. For extra radiation protection, make the dome deeper. Try placing a second plastic tarp layer over the dome, then pile up another 18 in (46 cm) of dirt.
Pack the earth around the entryways to seal out water. Stack a few shorter roofing poles or sandbags around each entrance. Tie them down tightly with rope or wire. Then, build up the earth around the poles into slopes 6 in (15 cm) deep to drive water away from the entryways. Make the slopes on all sides of each entryway to ensure that rainwater never enters the shelter.
Hang plastic canopies over the entryways to protect them from water. Extend a plastic tarp from the roof dome over the entryway. Sink a few stakes in the dome, then tie the tarp in place with strong cords or wires. Secure the other end of the tarp to the logs or sandbags stacked in front of the entryway to further waterproof your shelter. Make sure the tarps form a tent shape. They need to form a consistent slope so water rolls away from your shelter.
Installing Living Features
Install a hand-operated ventilation pump in the emergency exit. Choose a ventilation pump with a pipe about 20 in (51 cm) wide and 36 in (91 cm) tall. Place the filter on the floor next to the emergency exit. Then, run the pipe along the crawl space, letting it emerge preferably above the plastic canopy. Always use a pump with an option for manual operation. The pump will run on its own most of the time, but in case of an emergency, you can operate it to keep the shelter’s air clean.
Set up a toilet in a separate area of the shelter. You have several options for installing toilets. The most efficient way is a composting toilet, similar to what you would see in an RV. You will need to install a ventilation pipe, running it from the toilet to the surface. A good location for the toilet is near the exit furthest from your sleeping quarters. To install the ventilation pipe, run it through the nearest entryway, if possible. You may need to dig through the dirt so the pipe exits above the plastic canopy over the entryway. You can also try joining the pipe to the air pump’s ventilation pipe. Many shelters do not feature running water, so a regular toilet isn’t usually an option. You may not be able to get clean, running water in an emergency, so you may need to install an expensive system of tanks, pipes, and filters if you want more comfort. Another option is to use small plastic toilets or buckets. It isn’t ideal, but it is an effective way to keep your shelter safe and sanitary. Seal the buckets and carry them to the surface as needed.
Make beds and other furniture for the shelter. With a pole-covered trench shelter, the best way to set up furniture is to make hammocks. Loop strong rope or wire around the ceiling poles. Connect the rope or wire to cloth to create strong but lightweight hammocks. You can also try assembling poles and boards together to create bunk beds. You do not have to buy bulky furniture. Get creative and craft your own furniture or assemble makeshift bedding. For example, you can make a “bed” by piling blankets. Even packing together leaves, pine needle, or hay is a fast, inexpensive way to create a bed.
Pack food, water, and other necessities. Food and water are the most important supplies, so keep them in abundance. Plan on having at least 1 US gal (3.8 L) of water per person per day. Keep a supply of dry food that will last you about 2 weeks. Also bring along medical supplies, disposal bins, and extra clothing. You will generally need to be in the shelter for around 3 days, but plan on staying up to a month in case of a serious emergency. Get a good first-aid kit that includes bandages, tape, splints, scissors, rubbing alcohol, and any medication you need. For food, bring things that don’t require a lot of preparation, such as lentils, jerky, and military MREs.
Making a Shelter in a Building
Find a room made out of concrete. The best shelter rooms are underground, although you can convert any concrete room into a shelter. A basement is often a great place for a shelter. Also look for concrete office buildings or other protected structures unlikely to collapse during an event. If you have to make an indoors shelter, try to choose a room closer to the middle of the building. This will put as much space between you and the fallout as possible. You can also build a separate concrete room or shelter outside.
Shield the walls with heavy materials like sandbags. If you have time, stack sandbags near windows and other spots where radiation can leak in. The more you cover the walls, the more protection you have against radiation. Makeshift materials like mattresses, tables, books, and even bags of clothes help during an emergency.
Stock the shelter with food and other necessities. Plan on keeping enough supplies for at least 3 days. Fill it with clean, bottled water and snacks that don’t require much preparation. Be sure to include medical supplies and prescription medication. You will also need a sanitation bucket. A radio is handy, and you can use it to listen to updates. It may help you decide when leaving the shelter is safe.
Leave small vents for air at the entrances. Seal up the entrances with sandbags or other resistant material. Leave a small gap so that everyone in the shelter has enough air to breathe. Also consider installing an air ventilation pump. You may be able to connect it to ventilation pipes already installed in the building.
